The key to continuous gas sampling, especially when that sample used is a control or verifcation variable of the carbon potential control system, is maintaining clean and dry tubing, pumps, filters, and sensors.
The SSi sample tube contains an inner ceramic tube so that methane, propane (or any other hydrocarbon) does not catalyse in the tube. This can affect accuracy of samples and create soot blockages. The outer tube is RA330 alloy which will last up to 5 years in pit, sealed quench, and continuous furnaces. We have desgined three models for various applications. If you require a custom design please contact us with specifications.
Portable Gas Analyser Sample Tube
PART NUMBER 20263
| Designed for non-continuous use (i.e. where a single tube is manually swapped between multiple furnace) with PGA3510. |
| 31″ (787.4 mm) Sample Tube, RA330 Alloy |
| Maximum insertion length 22.125″ (561.9 mm) |
| Includes all valves, connectors, and fittings |
| 0.84″ (21 mm) O.D. steel tube with 0.19 ft. (57.9 mm) ceramic insert |
| Includes ball valve and 1″ (25.4 mm) NPT Nipple for mounting in a 1″ (25.4 mm) NPT bushing |
| Processes and Applications | Annealing, Carburising, Nitriding, Sintering |
|---|
Drawings
