The DPL4000 Portable Low Range Dew Point system used for accurate and reliable verification of gases using the latest in sensor technology.
It is commonly used for the verification of Hydrogen, Nitrogen or Argon dew point. Quick disconnect setup for use on multiple gas feed lines. Rapid response sensor used for quick readings.
Features
| Processes and Applications | Annealing, Sintering, Vacuum |
|---|
| Dew Point Range: | -112 to -22°F (-80 to -30°C) with ± 2.6°F (± 1.3°C) accuracy |
| Operating Temperature: | -40 to 140°F (-40 to 60°C) |
| Pressure Range: | 0 to 725 psi |
| Analog Outputs: | 4 – 20mA 0 – 20mA 0 – 1 V 0 – 10 V |
| Alarm Indication | Configurable |
| Sensor Threads: | NPT 1/2″ |
| Sensor Housing: | P65 – NEMA4 (AISI316L) |
Datasheets
DP2000/DPC2530/DPC3500 Datasheet
DPL4000 Datasheet
Manual
DP2000 Analyser Manual
DPC2530 Manual
DPC3500 Manual
DPL4000 Manual
Simple Dew Manual
Fixed Dew Point Analyser (Low Range)
